Composite cardboard production line - Welldoing trading limited

Short Description:

Product Detail

Product Tags

Our automatic paperboard production line has complete models. Please consult customer service for detailed customization parameters.

The Composite cardboard production line is suitable for combining 2-4 layers of 60-600g/m² roll gray board paper through hydraulic paper support, viaduct conveying, edge alignment, preheating, gluing, bonding, shaping, pulling, separation, slitting, cross-cutting, feeding and other processes into thick cardboard of various thicknesses and specifications required. The production line has the characteristics of reasonable design, compact structure, high degree of automation, convenient operation and maintenance, energy saving, etc., which makes up for many shortcomings of single-machine manual box gluing, greatly reduces production costs, improves product quality, and greatly improves the flatness, stiffness, surface finish, bonding strength, etc. of cardboard. It is an ideal equipment for making cardboard.

design speed	120m/min
work speed	40-100m/min
width:	1400-1600-2000mm
board length:	400mm-9999mm
cur precision:	±1mm
cut board thickness:	1-4mm
production:	3-4T/h
machine length:	around 84 meters(also produce depend on customer require)
power source:	110-220-380-440V
total power:	around 80kw(production around 50-60KW)

FAQ

1. Are you a factory or trading company?

We are both a factory and a trading company in this field . Our factory has been specializing in the production of a variety of cardboard carton manufacturing machinery for more than 10 years. Our machines are exported to many countries abroad. We have an experienced production R&D and after-sales service team!

2. What is the terms of payment you accept?

We usually accept the T/T payment, we need 30% of total amount as deposit,
pay the 70% balance before delivery, but we can also accept the L/C.

3. How does your factory do regarding quality control?

Quality is priority. We always regard great importance to quality controlling from the very small thing(even a small screw we will choose the best quality) from the beginning.

4. How is the packaging of the product?

A: Wrap it with wooden boxes or stretch film, fasten the machine to the container with steel wire rope, and weld the machine to the container with angle iron.

5. We don’t know how to operate the machine, how to deal with it?

We can send our engineers to your site and train your employees. You only need to bear the air tickets, accommodation, food and transfer expenses of our engineers in your country.
